Ilyushin IL-76

Aircraft
Name : Il-76
Manufacturer : ILYUSHIN
Body : Narrow
Wing : Fixed Wing
Position : High wing
Tail : T-tail
Engine : Jet
Engine Count : Multi
Position : Underwing mounted
Landing gear : Tricycle retractable

Characteristics:

Dimensions:
• Aircraft length: 46.6m
• Wingspan: 50.5 m
• Aircraft height: 14.76 m

Wing area: 300 m²

Weight:
• Maximum takeoff weight: 210 tons (actually 195 tons according to the register)
• Empty weight: 88.5 t
• Lifting capacity: up to 60 t

Fuel volume: 109,000 l
Fuel efficiency: 187 grams/tons/km at a range of 3,700 km (2,000 nautical miles)
Thrust maximum: 4 × 16,000 kgf
Engines: 4x-90A-76

Speed:

• Cruise speed: 780-850 km/h
• Minimum speed: 220 km/h

Payload up to: 40 ton
Number of paratroopers on board: 200

Cargo cabin size:

• Cargo cabin length: 24.54 m
• Width: 3.45 m
• Height: 3.4 m
• Volume: 321 m³

Aircraft resource: 30 years / 10,000 landings / 30,000 hours
